SEAFLO 33-Series Water Pressure Pump
The 33-Series is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. This 3-chamber diaphragm pump provides up to 3.0 gallons per minute and is capable of self-priming up to 9 vertical feet, and can run dry without damage. This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the faucet is opened and closed. They’re easy to install, service and winterize.
Features & Benefits
- Positive displacement pump
- Can run dry
- Quiet operation
- Demand pump
- Low amp draw
- Industry standard mount pattern
- Built in check valve
- Thermally protected
- Easy connect fitting
- Compact automatic demand water system pump
- Built-in pressure switch automatically starts and stops pump when faucet is opened and closed
- Capable of supplying multiple fixtures
- Self-priming so pump can be located in a location higher than the water tank
- Run-dry safe
- Built-in thermal protection
WATER PUMP
Type: Medium Duty 3 chamber positive displacement diaphragm pump, self priming, capable of being run dry
Mode: demand
Liquid Temperature: 140°F (60°C) Max.
Priming Capabilities: 6 feet (1.8 m) suction lift
Max Pressure: 45 PSI (3.1 bar)
Inlet/Outlet Ports: 1/2″-14 MNPT
MOTOR
Duty Cycle: Intermittent
Leads: 16 AWG, 4.5″ long with 2-Pin connector/Leads
Voltage: 12v/24v
